WAP

Products / PM-WANI / WAP

Product image

C-DOT Wireless Access Point (WAP) is a cost effective, high throughput, exceptionally reliable, modular and effective wireless solution for outdoor use cases such as Public Wi-Fi Hotspots. The Access Point complies to IEEE 802.11ac standard and is backward compatible to IEEE 802.11 a/b/g/n standards. The AP supports concurrent operation in dual band 2.4 GHz & 5 GHz. It supports 2×2 MIMO and 20, 40 & 80 MHz channel bandwidths.
What to do to become PDO ? (as per the plan of DOT- may be displayed later after the formalization from DOT)

  • Fill up the available registration form to become PDO
  • Once the form is submitted, the applicant may be mailed/SMS, list of PDOAs / ISPs in his area/DoT nodal officer contact
  • Further, the details of PDOs may be mailed to DDG(T) of respective LSA who have to take action/respond/facilitate etc

Dual Band Outdoor Wi-Fi 5 Access Point (WAP)
AGGRESSIVE EMS Pvt. Ltd.
  • Mr Prashant Mishra Director – Business Development M/s Aggressive Electronics Manufacturing Services Pvt. Ltd. Plot no. 264, SEC 6, IMT Manesar, Gurgaon - 122050, Haryana Mob. 9899113267, e-mail: prashant@aggressiveems.com
  • Mr. Mukul Sharma Assistant VP Aggressive Electronics Manufacturing Services PVT Ltd Plot No-264, Sec-6 IMT Manesar Gurgaon-122050, Haryana, India Mob.: +91 9818899029

• Standard :IEEE 802.11 a/b/g/n/ac • VLAN/QoS/Encryption/Authentication/Other standards : 802.1Q VLAN/802.11e/WMM/802.1x/802.11i/802.11s/WDS • Mode : Bridge • Operating Frequency : As per NFAP 2018 • Radio : 2 Wi-Fi Radios, Dual band (2.4 GHz & 5 GHz) concurrent operation • Coverage : 150 m • MIMO : 2×2 • Channel Width : 20/40/80 MHz • Clients : 64 concurrent users per radio. 128 per system • BSSID : 5 • Data Rate : 1166Mbps (n: 300 and ac: 866) • Services Supported : Voice, Video and Data • Features Supported : Rogue AP detection, WIDS, Self-healing and optimization • Operating Power : 10W (Max), Input Voltage Range: 10V to 60V DC • Power Source : PoE • WAN Port : 1x Ethernet Port – Gig bit auto-sensing • Audio indication : Yes (power up, booting, Ready) • Deployment Scenario : Outdoor Hotspot, Point to Point, Point to Multipoint, MESH • Max Tx Power : 28 dBm • PoE : 802.3af/at • Housing/Mounting : IP67, Pole mount, Lightning and Overvoltage Protection. Withstand high speed winds/thunderstorms • Operating condition : Temp. -20°C to +55°C, Humidity 10 to 95% non-condensing • Management : FCAPS through C-DOT EMS (SNMP based), C-DOT WAC Power Failure Alarm to NMS, Data and syslog capture for audit and analysis • Remote Upgrade : Yes • GUI : Yes • WANI Compliance : Yes • Authentication support : RADIUS protocol supported for external AAA server • Antenna : Internal Omni • Antenna Connector Type (Optional) : N(F) • Antenna Type supported (Optional) : Patch Panel, Omni, Sector, Grid

For PDO

  • Identifying PDOA or collaborating with PDOA to become a PDO
  • Arranging Internet Backhaul for the Access Points from TSP/ISP on commercial basis as PDO
  • Arranging for power and physical/civil infrastructure for Access Points installation
  • Arranging Access points from C-DOT Technology Manufacturing partners
For C-DOT
  • Providing WANI Compliant software to C-DOT Technology Manufacturing partners
  • Software support for Access Points
  • Software upgrade of Access points
For PDO Supplier
  • Testing of Access point for WANI
  • Hardware support for Access Points

• Standard :IEEE 802.11 a/b/g/n/ac • VLAN/QoS/Encryption/Authentication/Other standards : 802.1Q VLAN/802.11e/WMM/802.1x/802.11i/802.11s/WDS • Mode : Bridge • Operating Frequency : As per NFAP 2018 • Radio : 2 Wi-Fi Radios, Dual band (2.4 GHz & 5 GHz) concurrent operation • Coverage : 150 m • MIMO : 2×2 • Channel Width : 20/40/80 MHz • Clients : 64 concurrent users per radio. 128 per system • BSSID : 5 • Data Rate : 1166Mbps (n: 300 and ac: 866) • Services Supported : Voice, Video and Data • Features Supported : Rogue AP detection, WIDS, Self-healing and optimization • Operating Power : 10W (Max), Input Voltage Range: 10V to 60V DC • Power Source : PoE • WAN Port : 1x Ethernet Port – Gig bit auto-sensing • Audio indication : Yes (power up, booting, Ready) • Deployment Scenario : Outdoor Hotspot, Point to Point, Point to Multipoint, MESH • Max Tx Power : 28 dBm • PoE : 802.3af/at • Housing/Mounting : IP67, Pole mount, Lightning and Overvoltage Protection. Withstand high speed winds/thunderstorms • Operating condition : Temp. -20°C to +55°C, Humidity 10 to 95% non-condensing • Management : FCAPS through C-DOT EMS (SNMP based), C-DOT WAC Power Failure Alarm to NMS, Data and syslog capture for audit and analysis • Remote Upgrade : Yes • GUI : Yes • WANI Compliance : Yes • Authentication support : RADIUS protocol supported for external AAA server • Antenna : Internal Omni • Antenna Connector Type (Optional) : N(F) • Antenna Type supported (Optional) : Patch Panel, Omni, Sector, Grid

For PDO
  • Identifying PDOA or collaborating with PDOA to become a PDO
  • Arranging Internet Backhaul for the Access Points from TSP/ISP on commercial basis as PDO
  • Arranging for power and physical/civil infrastructure for Access Points installation
  • Arranging Access points from C-DOT Technology Manufacturing partners
For C-DOT
  • Providing WANI Compliant software to C-DOT Technology Manufacturing partners
  • Software support for Access Points
  • Software upgrade of Access points
For PDO Supplier
  • Testing of Access point for WANI
  • Hardware support for Access Points
